T-SQL 98 – My Technical Challenge – Clustered Index Conversion

This month’s T-SQL Tuesday subject has been selected by Arun Sirpal and is titled Your Technical Challenges Conquered. For my post I’m going to talk about the challenge of changing a Non-Clustered Primary Key into a Clustered one. This sounds relatively simple but gets more complicated as you delve into it.

First of all, what are the reasons for doing this? A table without a Clustered Index is called a HEAP. Now, heap tables do have their place but they’re not appropriate for most workloads in a relational database, they’re great if you need to insert a lot of data into a table quickly but reading from a heap is notoriously slow in most instances. Heap tables are stored on disk wherever SQL Server finds space, this can be spread around your disk. Clustered indexes are stored nicely ordered on disk and all of the data is stored together. You can monitor how many forward fetches you’re having from heap tables to see whether this particular issue is a problem for you.

Let’s assume that it is an issue and we want to add a clustered index to our table. A quick fix to this would be to just add a clustered index additionally to any other indexes we have on this table. This approach is a little messy though and isn’t the nicest way to fix this particular issue. There are exceptions, but generally if you have a Primary Key on a table then this will be your clustering key also (use cases may vary).

Unfortunately there isn’t a simple way to alter a table in order to turn a non clustered PK into a clustered one, this is because it’s such a fundamental change to how the data is stored on disk. In order to make this change you need to drop your existing primary key and then recreate it as a clustered primary key. Sounds simple right? Well, it can be, but it’s not as simple as that.

One thing about Primary Keys is that they can be used by Foreign Keys from other tables. You can’t drop a PK if there are FKs currently using it. Great, we’ll have to script all of these out, drop them, then recreate them after we’ve altered our table. We’re also going to assume that people have had the ability to alter our tables from whatever source control we have so we’ll have to do this dynamically.

One thing we wanted to check for was whether somebody had created a clustered index on the table but it was not on the primary key. In this use case I needed the clustered index to be on the primary key so we store the details of the other clustered index and drop that also.

You can get the sample scripts from my GitHub repo.

Script One – We’re just going to make some sample tables so that we can understand how this process works. Do not create these tables in a database that you care about (hands off production!).

Script Two – This shows the current status of our keys and how the tables relate to each other. Run this once you’ve run script one so you can see how it looks. Keep it around and we’ll run it after script three too. You should see something like this;

Take a look at the Foreign keys based on our main table and the clustered/nonclustered indexes. Check script one for more details on these.

Script Three – This is our script that’s going to actually do the work. Have a read through this script to get an idea of what it does. You’ll notice that I’ve commented out the execution statements. This is so that you’ll see what it’s planning to do in your messages tab in SSMS before it actually does anything. If you run it, you should see something like this;

As you can see, what it wants to do is to drop the two foreign keys first, it’s then going to drop the existing clustered index on our PKTest_Main table. It’s then going to recreate the primary key as a clustered one, once it’s done this it’s going to reapply the foreign keys. In this instance it’s also not going to reapply our old clustered index as it’s not necessary.

If you copy these messages into a new window and run them (or un-comment the exec statements in script three) it’s going to actually make the alterations above. Once this is done, the results from script two should look something like this;

You’ll notice that our primary key is now clustered and the unnecessary previous clustered index is no longer present. Lovely.

In production (and in change control) you’d probably want this as a stored procedure with the pass through parameters as @TableName = ” and (probably) @Execute = 1 (default 0) so that you don’t fire this proc by accident.

Let me know your thoughts on this, if you’d make any changes to any of the scripts.



Visualising the Marvel Cinematic Universe in T-SQL

This post is inspired by a blog post I saw here which showed an interesting way to visualise data. The example was not valid syntax for SQL Server so I thought I’d make a version that does work in T-SQL.

Let’s make some sample data. We’re going to use a list of all title characters (heroes with their own independent movies) in the MCU and which films they’ve played a role in.


IF OBJECT_ID('tempdb..#MCUData') IS NOT NULL DROP TABLE #MCUData
CREATE TABLE #MCUData (Hero_Name nvarchar(40), Movie_Name nvarchar(40), Release_Year int)
INSERT INTO #MCUData (Hero_Name, Movie_Name, Release_Year)
VALUES
 ('Iron Man', 'Iron Man', 2008)
,('The Hulk', 'The Incredible Hulk',2008)
,('Iron Man', 'Iron Man 2', 2010)
,('Thor', 'Thor', 2011)
,('Captain America', 'Captain America: The First Avenger', 2011)
,('Iron Man','Marvels The Avengers',2012)
,('The Hulk','Marvels The Avengers',2012)
,('Thor','Marvels The Avengers',2012)
,('Captain America','Marvels The Avengers',2012)
,('Iron Man', 'Iron Man 3', 2013)
,('Thor', 'Thor: The Dark World',2013)
,('Captain America', 'Captain America: The Winter Soldier',2014)
,('Star Lord', 'Guardians of the Galaxy',2014)
,('Iron Man','Avengers: Age of Ultron',2015)
,('The Hulk','Avengers: Age of Ultron',2015)
,('Thor','Avengers: Age of Ultron',2015)
,('Captain America','Avengers: Age of Ultron',2015)
,('Ant Man','Ant Man',2015)
,('Captain America','Captain America: Civil War',2016)
,('Iron Man','Captain America: Civil War',2016)
,('Thor','Captain America: Civil War',2016)
,('The Hulk','Captain America: Civil War',2016)
,('Ant Man','Captain America: Civil War',2016)
,('Spider-Man','Captain America: Civil War',2016)
,('Doctor Strange','Doctor Strange',2016)
,('Star Lord','Guardians of the Galaxy Vol. 2',2017)
,('Spider-Man','Spider-Man: Homecoming',2017)
,('Thor','Thor: Ragnarok',2017)
,('The Hulk','Thor: Ragnarok',2017)

Now, I wonder which character has appeared in the most movies. Let’s work that out. The nifty thing here is that we’re going to see the results in SSMS as a row graph chart, try this;

SELECT
     mcu.Hero_Name
    ,REPLICATE('|',(COUNT(*)/CONVERT(decimal,m.Movies))*100) Graph
FROM #MCUData mcu
CROSS JOIN (SELECT COUNT(DISTINCT Movie_Name) Movies FROM #MCUData) m
GROUP BY mcu.Hero_Name, m.Movies
ORDER BY mcu.Hero_Name

Take a look at the results pane, you can see that Iron Man and Thor are the most reoccurring Avengers with 35.3% movies each.


Please feel free to point out all of the reasons The list of characters & movies is wrong in the comments section below. I doubt I’d be able to stop you 🙂

Disk Speed Check

I regularly need to check the speed of disks on servers I jump on to. I found an excellent resource from a Microsoft Blogger named David Pless;

https://blogs.msdn.microsoft.com/dpless/2010/12/01/leveraging-sys-dm_io_virtual_file_stats/

It uses a number of counters from sys.dm_io_virtual_file_stats most of which are in milliseconds and bytes so they need to be aggregated for readability.

The script wasn’t *exactly* what I was after so I modified it to suit my needs. Here’s a sample of the output;

You’re more than welcome to grab a copy of this from my github. Feel free to make a pull request if you feel anything can be improved by changing this;

https://github.com/RichBenner/PersonalCode/blob/master/Disk_Speed_Check.sql

Temp Tables and Named Constraints

While doing some testing on using NEWSEQUENTIALID() I came across an interesting issue that may come to bite us in the future. I was making a proof of concept of a basic script using temporary tables, something like this (I’ve taken out the unnecessary bits);


IF OBJECT_ID('tempdb..#NewIDTest') IS NOT NULL DROP TABLE #NewIDTest
CREATE TABLE #NewIDTest (RowNum int, ID uniqueidentifier)

ALTER TABLE #NewIDTest ADD CONSTRAINT DF_NewIDTest_ID DEFAULT (newsequentialid()) FOR ID

The whole test script worked just fine, until I sent it to a colleague to help him understand the concept. When he attempted to run the script he was met with the following error;

Msg 2714, Level 16, State 5, Line 4
There is already an object named ‘DF_NewIDTest_ID’ in the database.
Msg 1750, Level 16, State 0, Line 4
Could not create constraint or index. See previous errors.

Turns out that even on (local) temporary tables, constraint names still need to be unique. I ran the first line of the statement above to drop the table and it worked just fine for him. Something to keep in mind for future.



The Nightmare of Corruption

What do you do when you come across an error like this?





You look around and check if anybody else looks like they want their day ruined. I’m betting not, so it’s your problem. First thing is to check that you have DBCC CHECKDB running regularly and set up to email out when errors occur so you can jump on it right away, you do have those running right? If so, excellent, get checking which was your last good backup and restore that. Append your new data since that date and you’re perfect.

If not, this is going to hurt.

First you need to see what you’re working with. Run DBCC CHECKDB on the database that’s corrupted and check the extent of your issue, be careful, this is a very IO intensive operation and will have a serious performance impact. If the corruption is in non clustered indexes then you can just rebuild said indexes, run CHECKDB again and make sure it’s fixed your corruption issues.

In the example here, we’ve got clustered indexes that are corrupt. This is a little more difficult to fix.

Table error: page (1:24441410) allocated to object ID 2025058250, index ID 1
CHECKDB found 2301 allocation errors and 34 consistency errors in database 'CorruptedDatabaseName'.

Now all is not yet lost, there are a couple of steps to take. You can try running DBCC CHECKDB with REPAIR_REBUILD check out books online. This is going to take longer than a normal CHECKDB but definitely worth it. It will show how many errors were fixed, if this does it then great, close this webpage and go back to your real job.

In this example, it didn’t work. Now, the next option is going to result in data loss. You want to make sure you have a full backup before you run this and you want to run it inside a transaction before committing so that you can rollback if you need to. DBCC CHECKDB REPAIR_ALLOW_DATA_LOSS is going to try to do it’s job and fix the corruption in your database. Again, this is going to hammer your IO but at this point you’re probably just focused on fixing this corruption.

CHECKDB found 2301 allocation errors and 1882 consistency errors in database 'CorruptedDatabaseName'.
CHECKDB fixed 2301 allocation errors and 0 consistency errors in database 'CorruptedDatabaseName'.

As you can see, the corruption wasn’t fixed by this. This means that we’re going to have to take really drastic action on this one. Fortunately in this scenario this database only has 10 tables. Ultimately the way this was fixed was by taking an empty copy of the corrupt database, transferring the data over to our new database and deleting the original. Yes, data loss was a sad fact in this but there wasn’t another way.

Conclusion: corruption fixed

FizzBuzz – My Approach

I’m sure you’re aware of the classic FizzBuzz interview question. The issue has always been on a simple way of populating the 100 rows of data, I’ve seen approaches with temp tables, cursors and loops. I don’t like these types of approach as they cause unnecessary overhead.

Here’s my take on the problem;


SELECT
    CASE WHEN a % 5 = 0 AND a % 3 = 0 THEN 'FizzBuzz'
         WHEN a % 3 = 0 THEN 'Fizz'
         WHEN a % 5 = 0 THEN 'Buzz'
         ELSE CONVERT(varchar,a) END
FROM (SELECT TOP 100
      ROW_NUMBER() OVER (ORDER BY (SELECT NULL)) a
      FROM sys.all_objects) a

Connect Item – Last Executed Time in SSMS

Something that has been bugging me for a while is that you can’t easily tell when the query in an SSMS window was last run. I’ve opened a connect item to see if we can get this addressed. I’d really appreciate if you could take the time to vote on it if you agree with the suggestion

https://connect.microsoft.com/SQLServer/feedback/details/3132936/ssms-show-execution-completed-time-date

Thanks in advance

Stack Dumps and Corruption

Had something I hadn’t had to deal with in a while appear yesterday on a client site, it’s something that we as DBA’s hope not to see, the dreaded Stack Dump. I’ll talk you through how I dealt with it.

Problem: Customer reported their hard drive was filling up on their SQL Server extremely fast and they were quickly running out of space.

Triage: A check later and there were 50GB of stack dump files appearing in their Log folder for SQL Server, now that’s something we need to look at. If your folder looks something like this then you’ve probably got a problem;

Yep, definitely going to need to check that...
Uh Oh

Checked the SQL Server error log and it was enormous with all of these stack dump errors. OK, let’s do this.

Treatment: The first place to look was those stack dump files to see what was going on. When a stack dump occurs SQL Server will create 3 separate files, a .txt, a .log and a .mdmp file. If you take a look in the txt file you will see a whole lot of data that’s only really useful to Microsoft support, but there’s some useful information in there if you take the time to dig through it. Take a look at the Input Buffer output, this contains 255 bytes of the query that’s being dumped, recognise it? In my scenario I had dealt with this query before so I could quickly find it but you may have to search through your code repository to find the query that’s being the victim of the dump.

Exhibit A – The Culprit

Now this is a query that runs regularly to keep some summary tables updated. Fortunately I was able to switch this off while investigating the issue, if you can’t switch it off then you’re going to have to clear out some of those dump files if you start running out of space while you investigate.

Now the bleed is stopped, time to work out what’s causing the dump. Take a look at the major and minor exception codes, a quick google shows that problem code 5242 is likely a corruption issue. An out of hours run of DBCC CHECKDB (it’s high impact, you don’t want to do this in production) showed that one particular index was showing as having corruption. Damn. Let’s try to fix that now shall we. CHECKDB gives us the object_id and index_id of the culprit, let’s use this information to find out which particular index in the issue;


USE [YourDatabaseName]
GO

SELECT
     o.name Table_Name
    ,i.name Index_Name
FROM sys.objects o
JOIN sys.indexes i
     ON o.object_id = i.object_id
WHERE o.object_id = 'YourObjectID'
     AND i.index_id = 'YourIndexID'

It’s a Non Clustered Index: If this is a non-clustered index then you’re golden. Navigate to the index in management studio, then you can create the drop and create script;

Bear in mind that this will affect the performance of your live system and may cause or be the victim of blocking. Once you’ve got a maintenance window and your users are aware then go ahead and run this script, it’s going to drop the index and create a fresh one using the corrected data. Once this has run, go ahead and run DBCC CHECKDB again to ensure that the corruption issue is fixed. If it is then great, you can clear down those stack dumps to free up hard drive space, tidy up after yourself and go get a cuppa and a biscuit and pat yourself on the back for a job well done.

It’s a Clustered Index: This is different, and a whole different beast. A clustered index is the table, it’s not just an index on the table, the clustered index is how it is stored on disk. Ultimately you’re going to have to restore your database from your last good backup (please restore to a different location, don’t instantly overwrite your production database) and retrieve your data that way. It’s not ideal but it is one of the few ways of recovering from this corruption.

Plus, remember, you always have the option of raising a ticket with Microsoft Support if you can’t fix it yourself. That’s what all of that other junk is for in the dump files.

T-SQL Tuesday #86

I always enjoy reading through Microsoft Connect items and seeing what people smarter than me are looking for out of SQL Server. Inspired by this post from Mr Brent Ozar himself, I thought I’d make a note about one of the more interesting ones and the advantages/disadvantages as I see them.

A bit of background: I work for a software vendor that provides document information management systems (among other things). The servers that run this can be anything since Microsoft 2008 and are run on the customer’s hardware. The SQL Server may well be virtualised and it’s not unusual to see the server being a shared SQL/Web box (although this can be a nightmare to troubleshoot). This makes an interesting situation on each customer’s machine as they’re all unique, any triage tools need to be compatible back to SQL 2008 and versatile to catch as much information as possible. It also means that troubleshooting usually needs to be completed on the customer’s live site as we do not have anything locally that will mirror the specs exactly.

While browsing Microsoft connect one day I came across this connect item which seemed like a good idea. The premise is that there would be functionality to export and import some sort of settings file which, in my case, would allow for a certain amount of troubleshooting remotely by grabbing this file and installing onto a test server.

Advantages:

  • Would definitely help troubleshooting.
  • Could even post on Stack Overflow to help diagnose settings issues remotely.
  • Would avoid needing to go through a long list of settings on a new install to ensure they’re all set correctly.

Disadvantages:

  • Won’t allow for any troubleshooting of the data itself (although a .bak file would help there).
  • This would be a nightmare at a server setting level, and some settings are based upon hardware configuration (think MAXDOP).
  • What about tempdb files and backup locations, they’re going to need physical file locations passing through. This is going to require a certain level of GUI.
  • It’s going to reduce the level of knowledge of people performing new installs, this seems like a short term time saver at the detriment of people’s knowledge overall.

This one has been closed by Microsoft as “Won’t Fix” but this doesn’t always mean a death knell for the suggestion. This particular one is a bit of a minefield though so I’m not expecting it to get implemented any time soon.

I’d be interested to know your thoughts around this.

Edit: As Paul mentioned in the comments, the connect item above is to do with SSMS settings, not server level. Because of this I’ve opened the connect item below, please feel free to upvote it if you believe it may be useful;



https://connect.microsoft.com/SQLServer/feedback/details/3119156/functionality-to-export-server-settings-and-import-to-another-server



Contributing to Open Source

I’ve always been a fan of giving back wherever possible.

I work for a software vendor where each customer hosts their own SQL Server on site, which means that I indirectly support about 400 servers around the world, all of which have different hardware specifications and unique things to think about. A lot of what I do is jumping on customer’s sick SQL Servers, working out what’s wrong and working out a solution. I use a number of tools so that I can gather information automatically rather than manually pull it each time.

A major set of tools that I use is the Brent Ozar First Responder Kit. This is an excellent set of tools that give a great range of stats about your SQL Server and links to read further if you’re unsure what the stats mean. This is great for getting people with less experience up to speed and still extremely useful for more experienced users.

I’ve got a .NET tool which runs these scripts (among others) and exports to Excel, such a time saver. I added additional checks on my local versions for things that were specific to what I wanted that weren’t in the main scripts (I still do for certain things that may be unsuitable to be included in the main scripts, see my recent post on sp_regread).

In June 2016 these scripts were open sourced the team open sourced these scripts and put them up on GitHub. After browsing the issue list I decided to help out a little in order to give back and make these scripts even more useful for others. The changes I’ve made aren’t large ones but there is definitely a sense of accomplishment when those pull requests get accepted.



This kit gets released once a month and they credit who has coded on the release, it’s nice seeing your name on their release notes (e.g. here and here). It will also not be a bad thing for the old CV when it comes to it, you get your own profile which details what you’ve been contributing on. You even get a cool little graph which tells you the volume of your own contributions.

If you’ve ever seen an open source project that you thought it might be fun to contribute to, I urge you to go ahead and give it a go.
